品牌：Anchmold
加工定制：是
加工设备数量：10
起订：1副
供应：200000副
| 加工定制 | 是 |
|---|---|
| 加工设备数量 | 10 |
| 加工能力 | 200000pieces |
| 作用对象 | 钨 |
| 模具材质 | 金刚石 |
| 适用范围 | 家电,医疗,电子 |
| 质量体系 | iso9001 |
| 品牌 | Anchmold |
Anchors Mold is a manufacturer of highcrystalline diamond drawing dies are high quality, predictable and durable product for drawing ferrous and non-ferrous wires 0.01 to 8.00 mm.
Key benefits of Anchors Mold HCD wire dies
• Long die life due to its extreme hardness and resistance to scratching
• Can be used in high-heat processes because of its extreme thermal conductivity
• Blanks are thermally stable up to 1700°C (3092°F)
• Easy **p, smooth drawing
• ** of all diamonds are checked for inclusions, cracks
• Nonconductive properties make this product a good choice when electrical conductive materials are an issue
Applicability
HCD wire dies are still successfully used for applications that require excellent wire surface qualities, high heat resistance and in applications that require a die material that is not electrically conductive.
Typical application areas:
• Tungsten filament wire
• Bonding wire (gold, copper, aluminum)
• Medical wire
• Stainless steel wire
• Copper wire
• EDM wire
• Special alloy and high performance alloy wire
• Precious metal wire
• Various other ferrous and non-ferrous metal wire types
